Falc TLF

Falc TLF
  • Reinforced 3 point linkage with Cat 1 & 2 clevis mounting
  • Left hand offset. (Right hand offset is available on request)
  • 4mm body plate with replaceable 2.5mm wear and tear sheet
  • 540 rpm PTO standard on 1600 & 2000 models (1000 rpm available by inverting the drive pulleys)
  • 1000 rpm PTO only on the 2500 model
  • Drive shaft fitted with a free wheeling clutch and 6 spline, 1 3/8” yoke
  • Side drive is via 5 x SPB ‘V’ belts. ( The TLF 2500 has SPB 3000/5 banded belts as standard)
  • Hydraulically operated lateral side shift to 60cm. Mechanical
  • breakaway with automatic re-set
  • Hydraulic float system for contour following
  • Flexible coupling joint between gearbox and rotor to absorb shocks and vibrations
  • Lowering speed of the mower head adjustable via hydraulic valve
  • Height control by adjustable rear roller: 0 -125mm
  • 140mm dia. dynamically balanced rotor (10mm wall thickness)
  • Special, dual pivoting Boron steel blades
  • Capable of cutting from 90° above horizontal to 70° below
  • Low profile
SeriesKG.LBS.N.HP
160099021834870-120
2000107023596080-120
2500132029107890-120
