Falc Smart

Falc Smart
  • 3pt linkage, centrally mounted
  • Floating clevis hitch with Cat 2 pins (Cat 2/3 pins on the 3500 & 4000)
  • Drive shaft with 1 3/8″ 6 spline yoke and fitted with friction plate clutch
  • 140 hp, single speed gearbox
  • Rotor speeds of: 348 rpm at 540 rpm PTO or 362 rpm at 1000 rpm PTO (Additional gears for other speeds available as an option)
  • Front square tube 80mm x 80mm x 6mm (2500 & 3000) and 80mm x 120mm x 6mm (3500& 4000)
  • Tapered Roller Bearings on all rotor output shafts
  • Quick release tynes
  • Rear PTO shaft for ancillary equipment
  • Rear levelling bar with manual ‘screw’ type adjustment system
  • Round tyne mounting flange (to which an optional stone protector can be fitted)
  • Full CE safety guarding on all models
  • Depth control via 8 Tube Cage Roller
  • Side protection shields
SeriesA mm.Kg.LBS.Ø mm.N.HP
25002591111024484601060-140
30003091131028884601260-140
