Falc Magnum

Falc Magnum
  • 3pt linkage, centrally mounted
  • Floating clevis hitch with Cat 2/3 pins
  • Drive shaft with automatic torque limiter (1 3/8″ 6 spline yoke on 3000 and 1 3/8″ 21 spline yoke on 3500-5000)
  • 240 hp, single speed gearbox
  • Rotor speed: 365 rpm at 1000 rpm PTO (Additional gears for other speeds available as an option)
  • Tapered Roller Bearings on all rotor output shafts
  • Quick release tynes
  • Front square tube 80mm x 120mm x 6mm
  • Rear PTO shaft for ancillary equipment
  • Rear leveling bar with manual ‘screw’ type adjustment system
  • Round tyne mounting flange (to which an optional stone protector can be fitted)
  • Full CE safety guarding on all models
  • Depth control via 8 Tube Cage Roller
SeriesA mm.Kg.LBS.Ø mm.N.HP
300031151730381455012100-240
350036072020445355014120-240
400040992310509355016130-240
450045912600573255018150-240
500050832890637155020160-240
